Fridge Box

12

m³ Cargo Volume

3400 × 1990 × 1840 mm cargo bay

N1:405/N2:1155

kg Max Payload

GVW 3500 kg (N1 class) 4250 kg (N2 class)

97.4

kWh Battery

600 V electrical architecture

150

kW Peak Power

Rear-wheel drive

INTELLIGENT DRIVING & CARGO MANAGEMENT

Specialist refrigeration and intelligent cargo management keep operations efficient and
under control from start to finish.

12.8-inch central touchscreen with integrated control for the electric refrigeration unit

OTA software updates

Driver Monitoring System (DMS)

L2 Advanced Driver Assistance Systems

360° Surround-View + height detection radar

V2L Power Supply ( 3.3 kW x 2 )

E-PTO ( 10 kW )

Electric refrigeration unit, touchscreen-controlled, with 220 V pre-conditioning connection

Full-route temperature tracking and logging

Walk-in cargo space

Loading capacity can accommodate up to 5 Euro pallets

Easy access with integrated handles and steps

High-performance ATP Insulated Body

Overload detection + automatic cargo compartment lighting

Real-time payload monitoring and control system

WHERE DELIVAN FITS

One van for temperature-sensitive cargo
and on-time deliveries

These are the applications where DELIVAN refrigerated conversion shines

— where goods stay temperature-controlled, shipments stay on track,

and deliveries arrive in perfect condition.

FRESH PRODUCE DELIVERY

Keep perishables fresh along every route

Precise temperature control ensures the premium quality of dairy products, fish, meat, and fresh produce throughout delivery.

FOOD TRANSPORT

Safe temperature control for packaged food shipments

Reliable refrigeration protects pre-packaged food throughout the whole transit.

PHARMACEUTICAL
COLD CHAIN

Precise temperature monitoring for sensitive medical goods

Strict temperature tracking ensures pharmaceutical products are transported in compliance.

CATERING SUPPLY

Consistent cooling for daily catering ingredient runs

Deliver fresh raw materials and prepped food to restaurants and catering sites on schedule

RETAIL RESTOCK

Efficient restock for retail store shelves

Support regular cold goods replenishment for supermarkets and retail outlets.

TECHNICAL SPECIFICATIONS

Overall Dimensions (L × W × H, without mirrors)6036 × 2060 × 2850 mm
Seating Capacity3
Drive ConfigurationRear-wheel drive (RWD)
Wheelbase3880 mm
Body ConstructionBody-on-frame with independent chassis structure
Gross Vehicle Weight (GVW)3500 kg(N1) / 4250 kg (N2)
Chassis Kerb Weight2142 kg
Box Weight953 kg
Maximum Payload (excluding driver and passengers) 405 kg(N1) / 1155 kg (N2)
Cargo Dimensions3400 × 1990 × 1840 mm
Cargo Volume12 m³
Peak Power150 kW
Battery Capacity97.4 kWh
Electrical Architecture600 V
Min Turning Radius7 m
SuspensionFront double wishbone / Rear leaf springs
BrakesFront and rear disc brakes
Tyre Size215 / 75 R16 LT 10PR (N1) / 215 / 75 R16 LT 12PR (N2)
